Information supply pump
BOSCH
9 440 610 580
9440610580
ZEXEL
105207-1540
1052071540

Rating:
Scheme ###:
1. | [1] | 152051-1820 | PUMP HOUSING |
5. | [1] | 152100-1120 | PUMP PLUNGER |
6. | [1] | 152102-0400 | COMPRESSION SPRING |
7. | [1] | 152105-1500 | CAPSULE |
8. | [1] | 029332-6030 | GASKET |
10. | [1] | 152111-4020 | TAPPET |
10/2. | [1] | 152112-0500 | ROLLER |
10/3. | [1] | 152113-1000 | BEARING PIN |
10/4. | [2] | 152114-1700 | SLIDER |
14. | [2] | 152115-0500 | VALVE BODY |
14. | [2] | 152115-0500 | VALVE BODY |
15. | [2] | 152116-0200 | COILED SPRING |
15. | [2] | 152116-0200 | COILED SPRING |
16. | [1] | 152117-0620 | CAPSULE |
18. | [1] | 029631-6060 | O-RING |
19. | [1] | 029631-6060 | O-RING |
20. | [2] | 152121-0200 | LOCKING WASHER |
25. | [1] | 152200-5420 | HAND PRIMER |
30. | [1] | 152300-7120 | EYE BOLT |
32. | [1] | 029731-4570 | EYE BOLT |
35. | [2] | 029341-4130 | GASKET D20&13.8T2* |
36. | [2] | 029341-4130 | GASKET |
Cross reference number
Zexel num
Bosch num
Firm num
Name
Information:
Do not operate or work on this product unless you have read and understood the instruction and warnings in the relevant Operation and Maintenance Manuals and relevant service literature. Failure to follow the instructions or heed the warnings could result in injury or death. Proper care is your responsibility.
The new harness is more durable than the previous harness. The new wiring harness incorporated more support at the connector and is easier to assemble.The new injector harness is adaptable to the above engines back to first production.The required part number is listed in Table 1.
Table 1
Required Parts
Qty Part Number Part Name Former Part Number
1 582-8173 Harness As. 415-1169 This change is effective with the serial numbers listed in Table 2.
Table 2
Effective Serial Numbers
S/N:3B9138-UP
S/N:R4F144-UP
