Information fuel-injection pump
BOSCH
F 01G 09Y 021
f01g09y021
ZEXEL
104206-4070
1042064070
ISHIKAWAJIMA-S
131011080
131011080
Rating:
Compare Prices: .
As an associate, we earn commssions on qualifying purchases through the links below
Fuel Injection Pump 104206-4070 131011080 for Perkins Engine 404D-15
AUCALIWI Part number:104206-4070,131011080 || Application:for Perkins Engine 404D-15
AUCALIWI Part number:104206-4070,131011080 || Application:for Perkins Engine 404D-15
Fuel Injection Pump 131011080 104206-4070 Compatible with 404D-15 Engine for JCB Zexel
DJCXYSM Product Name:Fuel Injection Pump || Part Number:104206-4070 131011080 104206-4070 || Application: Compatible with 404D-15 Engine Compatible with JCB Zexel || NOTE: To avoid unnecessary returns please check the part number before purchasing or tell us the picture of your engine model and nameplate to reduce the error rate. || Tip: If you have any questions before or after sale please contact us in time. We'll help you out as soon as possible.
DJCXYSM Product Name:Fuel Injection Pump || Part Number:104206-4070 131011080 104206-4070 || Application: Compatible with 404D-15 Engine Compatible with JCB Zexel || NOTE: To avoid unnecessary returns please check the part number before purchasing or tell us the picture of your engine model and nameplate to reduce the error rate. || Tip: If you have any questions before or after sale please contact us in time. We'll help you out as soon as possible.
131011080 104206-4070 1042064070 F01G09Y021 Fuel Injection Pump for Perkins 404D-15 Engine
HIRINTOL 🔸Replace Part Number: 131011080, 104206-4070, 1042064070, F01G09Y021 || 🔸Compatible Model: for Perkins 404D-15 Engine || 🔸Efficient And Stable: Using advanced technology, it can provide efficient and stable fuel supply to ensure the normal operation of the vehicle. || 🔸Durable And Reliable: Tested and proven many times, it has a long life and reliable quality to keep working under extreme conditions. || 🔸Easy Installation: standard interface design, easy installation, plug and play, no professional skills required.
HIRINTOL 🔸Replace Part Number: 131011080, 104206-4070, 1042064070, F01G09Y021 || 🔸Compatible Model: for Perkins 404D-15 Engine || 🔸Efficient And Stable: Using advanced technology, it can provide efficient and stable fuel supply to ensure the normal operation of the vehicle. || 🔸Durable And Reliable: Tested and proven many times, it has a long life and reliable quality to keep working under extreme conditions. || 🔸Easy Installation: standard interface design, easy installation, plug and play, no professional skills required.
Components :
| 0. | INJECTION-PUMP ASSEMBLY | 104206-4070 |
| 1. | _ | |
| 2. | FUEL INJECTION PUMP | |
| 3. | NUMBER PLATE | |
| 4. | _ | |
| 5. | CAPSULE | |
| 6. | ADJUSTING DEVICE | |
| 7. | NOZZLE AND HOLDER ASSY | 105148-1761 |
| 8. | Nozzle and Holder | |
| 9. | Open Pre:MPa(Kqf/cm2) | 14.7{150} |
| 10. | NOZZLE-HOLDER | 105078-0300 |
| 11. | NOZZLE | 105007-1330 |
Scheme ###:
| 5. | [4] | 140161-0620 | PLUNGER-AND-BARREL ASSY "M35" |
| 12. | [4] | 140110-4320 | DELIVERY-VALVE ASSEMBLY K24 |
| 13. | [4] | 140112-2800 | COMPRESSION SPRING |
| 16. | [4] | 140115-2200 | GASKET |
| 17. | [4] | 140116-7220 | FITTING |
| 20. | [4] | 140118-0500 | O-RING |
| 30. | [4] | 140131-0021 | FLANGE BUSHING |
| 31. | [4] | 140271-0000 | BEARING PIN |
| 32. | [8] | 140118-0400 | O-RING |
| 37. | [8] | 140124-0100 | FLAT-HEAD SCREW |
| 40. | [4] | 140200-3220 | TAPPET |
| 44. | [4] | 140212-0300 | BEARING PIN |
| 45. | [1] | 140213-1200 | LOCKING WASHER |
| 50. | [4] | 140215-2000 | COMPRESSION SPRING |
| 51. | [4] | 140216-1300 | SLOTTED WASHER |
| 52. | [4] | 140254-2900 | SLOTTED WASHER |
| 53/1. | [1] | 140254-1400 | PLATE T1.80 |
| 53/1. | [1] | 140254-1500 | PLATE T1.85 |
| 53/1. | [1] | 140254-1600 | PLATE T1.90 |
| 53/1. | [1] | 140254-1700 | PLATE T1.95 |
| 53/1. | [1] | 140254-1800 | PLATE T2.00 |
| 53/1. | [1] | 140254-1900 | PLATE T2.05 |
| 53/1. | [1] | 140254-2000 | PLATE T2.10 |
| 53/1. | [1] | 140254-2100 | PLATE T2.15 |
| 53/1. | [1] | 140254-2200 | PLATE T2.20 |
| 53/1. | [1] | 140254-2300 | PLATE T2.25 |
| 53/1. | [1] | 140254-2400 | PLATE T2.30 |
| 53/1. | [1] | 140254-2500 | PLATE T2.35 |
| 53/1. | [1] | 140254-2600 | PLATE T2.40 |
| 53/1. | [1] | 140254-2700 | PLATE T2.45 |
| 53/1. | [1] | 140254-2800 | PLATE T2.50 |
| 53/1. | [1] | 140254-3100 | PLATE T1.825 |
| 53/1. | [1] | 140254-3200 | PLATE T1.875 |
| 53/1. | [1] | 140254-3300 | PLATE T1.925 |
| 53/1. | [1] | 140254-3400 | PLATE T1.975 |
| 53/1. | [1] | 140254-3500 | PLATE T2.025 |
| 53/1. | [1] | 140254-3600 | PLATE T2.075 |
| 53/1. | [1] | 140254-3700 | PLATE T2.125 |
| 53/1. | [1] | 140254-3800 | PLATE T2.175 |
| 53/1. | [1] | 140254-3900 | PLATE T2.225 |
| 53/1. | [1] | 140254-4000 | PLATE T2.275 |
| 53/1. | [1] | 140254-4100 | PLATE T2.325 |
| 53/1. | [1] | 140254-4200 | PLATE T2.375 |
| 53/1. | [1] | 140254-4300 | PLATE T2.425 |
| 53/1. | [1] | 140254-4400 | PLATE T2.475 |
| 53/1. | [1] | 140254-4500 | PLATE T2.525 |
| 60. | [1] | 140243-7920 | CONTROL ROD |
| 65. | [1] | 140262-1700 | PLATE |
| 66. | [5] | 140252-0001 | FLAT-HEAD SCREW |
| 77. | [4] | 140241-4021 | CONTROL SLEEVE |
| 93. | [1] | 140402-3520 | EYE BOLT |
| 93/1. | [1] | 140402-3500 | EYE BOLT |
| 93/2. | [3] | 026510-1340 | GASKET |
| 93/3. | [1] | 140401-0700 | BUSHING |
| 93/4. | [1] | 029711-0130 | INLET UNION |
| 110. | [1] | 140420-2400 | BLEEDER SCREW |
| 111. | [1] | 026506-1040 | GASKET |
| 900. | [1] | 140191-2220 | PLUNGER-AND-BARREL ASSY |
| 900/5. | [1] | 140161-0620 | PLUNGER-AND-BARREL ASSY "M35" |
| 900/12. | [1] | 140110-4320 | DELIVERY-VALVE ASSEMBLY K24 |
| 900/13. | [1] | 140112-2800 | COMPRESSION SPRING |
| 900/16. | [1] | 140115-2200 | GASKET |
| 900/17. | [1] | 140116-7220 | FITTING |
| 900/20. | [1] | 140118-0500 | O-RING |
| 900/30. | [1] | 140131-0021 | FLANGE BUSHING |
| 900/31. | [1] | 140271-0000 | BEARING PIN |
| 900/32. | [2] | 140118-0400 | O-RING |
